Module
WBR-2203
Push Switch Delay Off Module Transform electric device(s) to wireless control with module receiver working in conjunction with ARC wireless remote control and at the same time keeping the existing wired wall switch.
Compatible to L and M series AC and Voltage free output receiver module Delay timer function – 0, 1s, 3s, 30s, 60s. Compatible with standard wired Push Switch. 32 memories, first in first out storage maintain. Fits into standard wall box.
Input Rating: 230V~50Hz Output Rating: 1. AC Output 2300W Resistive Load 2. Voltage Free (Dry port) Radio Frequency: 433.92MHz Power Consumption: <1W Environment Temperature: 0-40 ºC Range: Up to 50 Meter range (Depends on building materials)
